Platform: Scalpel
Model Name: Scalpel 4
Model Code: C24504U
Frameset
Frame: Scalpel, lightweight carbon construction, 120mm travel, Proportional Response Suspension and Geometry, FlexPivot Chainstay, full internal cable routing, 73mm BSA, 1.5″ headtube with 1-1/8″ upper reducer/internal cable guide, 148x12mm thru axle, 55mm chainline, UDH, post-mount disc – 160mm native
Fork: RockShox SID, 120mm, DebonAir, 15x110mm thru-axle, tapered steerer, 44mm offset, TwistLoc remote dual lockout
Headset: Acros ICR
Rear Shock: RockShox SIDLuxe Select+, 2-Pos mode adjust, adjustable rebound, 190×45, TwistLoc remote dual lockout
Drivetrain
Rear Derailleur: Shimano Deore 6100
Shifters: Shimano Deore 6100, 12-speed
Chain: Shimano Deore, 12-speed
Crank: Shimano M5121, 32T
Rear Cogs: Shimano Deore, 10-51, 12-speed
Bottom Bracket: Shimano BSA 73mm
Brakes
Brakes: Shimano MT501, hydraulic disc, 180/160mm RT10 rotors
Brake Levers: Shimano MT501 hydraulic disc
Wheels
Rims: Stan’s NoTubes Crest S2, 32h, tubeless ready
Spokes: DT Swiss Champion
Tire Size: 2.4
Wheel Size: 29
Hubs: (F) Shimano TC-500, 15x110mm thru-axle / (R) Shimano MT410B, 12x148mm thru-axle
Tires: (F) Maxxis Rekon Race WT, 29×2.4″, EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29×2.4″, EXO Protection, tubeless ready
Components
Handlebar: Cannondale 2 Flat, butted 2014 Alloy, 31.8mm, 3° rise, 8° sweep, 760mm
Stem: Cannondale C1 Conceal, Alloy, 31.8, -6°
Grips: RockShox Smooth Silicone
Saddle: Prologo Dimension NDR, STN rails
Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M-XL)
Connectivity
Components: Cannondale Wheel Sensor
Please note that, based on component availability and other factors, specifications are subject to change without notice.
