Description
Frame: CF4; full carbon; 160mm travel; fixed battery; Tapered head tube, 148 x 12mm axle standard. Max. tyre size 29″ x 2.6″
Rear Shock: Fox Float X Factory
Fork: Fox 36 Float Factory; Air, 160mm travel; Tapered; 44mm fork offset; 29×2.6″ max. tyre size
Headset: Acros ICR Merida integrated neck with Blocklock
Stem: Merida Expert eTR II; aluminium; 35 DSH; 0 ASD; Supernova mount. 40 mm all sizes
Handlebar: Race Face Era; 780mm wide
Grip: Merida Expert EC
Brake Type: Hydraulic disc
Brake Lever: SRAM Maven
Front Brake: SRAM Maven Ultimate 4 piston hydraulic disc brake with SRAM HS2; 200mm rotor
Rear Brake: SRAM Maven Ultimate 4 piston hydraulic disc brake with SRAM HS2; 200mm rotor
Front Tyre: Maxxis Assegai; 29×2.5″; kevlar bead; TR EXO+ 3C MaxxGrip
Rear Tyre: Maxxis Minion DHR II; 29×2.4″; kevlar bead; TR EXO+ 3C MaxxTerra
Wheel Size: 29″ / 27.5″
Rim: Part of wheelset -FSA SC30; 30mm inner rim width; carbon; Tubeless ready (tubeless tape and valves included)
Spokes: Part of wheelset
Front Hub: Part of wheelset – FSA SC30; 110x15mm; 6-Bolt
Rear Hub: Part of wheelset – FSA SC30; 148x12mm; 6-Bolt; SRAM XD with Merida Expert TR axle; including removeable lever, 6/4mm allen key
Speeds: 12
Rear Derailleur: SRAM XX Eagle Transmission AXS
Shift Levers: SRAM AXS Pod Ultimate Controller
Chain: SRAM XX Eagle; Flattop
Cassette: SRAM XX Eagle Transmission ; 10-52; 12 speed
Chainset: SRAM XX Eagle Transmission E-MTB for BOSCH; 34 teeth. SRAM XX Eagle E-MTB Crank; 165 mm for all sizes
Bottom Bracket: Attached
Pedals: VP VP-532
Saddle: PROXIM Nembo Steel; V-mount adapter; incl. Merida minitool
Seat Post: Fox Transfer Factory Series; 34,9mm diameter; 0 mm lay back;
Motor: Bosch CompactTube (CPT); 400Wh, Bosch Performance Line SX
Battery Capacity: 400Wh
eBike Display: Bosch Purion 400
