Description
Frame: CF3 carbon, Nano Matrix for impact resistance.Internal cable routing, 142 x12mm axle standard, BB86 BB standard, flat mount rear brake with Disc Cooler, 1 1/2″ headtube. Fully integrated seat clamp. Max tyre size 700 x 35c (700 x 32c with mudguard)
Fork: Scultura Endurance CF3 Disc; full carbon, tapered steerer. Disc Cooler; Max tyre size: 700 x 35c (700 x 32c with mudguard)
Headset: Merida Team SL (SE-301 neck)
Stem: Merida Expert SL 2PII; aluminium; -9 degree rise – Length- 90mm (XXS-XS-S), 100mm (M), 110mm (L/XL)
Handlebar: Merida Expert SLII; aluminium; 380mm (XXS-XS-S), 400mm (M-L), 420mm (XL)
Grip: Merida Expert
Brake Type: Hydraulic disc
Brake Lever: Shimano 105
Front Brake: Shimano 105; Hydraulic disc brake caliper with Shimano RT54; 160mm rotor
Rear Brake: Shimano 105; Hydraulic disc brake caliper with Shimano RT54; 160mm rotor
Front Tyre: Maxxis RE-FUSE; 700 x 32C; Kevlar bead
Rear Tyre: Maxxis RE-FUSE; 700 x 32C; Kevlar bead
Wheel Size: 700c
Rim: Merida Expert SLII; 23mm inner rim width; 25mm rim depth; aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes: Double Butted Black stainless
Front Hub: Shimano HB-TC500; 100 x 12mm; 28 spoke; Centerlock
Rear Hub: Shimano FH-TC500-HL; 142 x 12mm; 28 spoke; Centerlock
Speeds: 24
Front Derailleur: Shimano 105
Rear Derailleur: Shimano 105; GS
Shift Levers: Shimano 105 disc
Chain: Shimano CN-M6100-12
Cassette: Shimano CS-R7101; 11-34 teeth; 12 speed
Chainset: Shimano 105; FCR7100, 50-34 tooth chainset; Crank length – 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
Bottom Bracket: SM-BB71-41B, Pressfit 86.5
Saddle: Merida Comp SL; V-mount – made with 25% recycled material
Seat Post: Merida Expert CC; 27.2mm diameter; 15mm layback; Carbon
