Description
Frame: TFS – 6061 series aluminium tubing, double butted andtechnoformed. Tapered head tube. Inboard chain stay mounted disc brake. Internal cable routing, BSA BB standard. Max tyre size 27″ x 2.25″
Fork: X-Fusion RC32 120mm; 120 mm travel; Lockout; 46mm fork offset; 27.5×2.4″ max. tyre size
Headset: FSA NO.55R/57SC/57B
Stem: Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise
Handlebar: Merida CC; material: aluminium; 640mm wide; 15mm rise
Grip: Merida Expert JR
Brake Type: Hydraulic Disc
Front Brake: Tektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-35; 160mm
Rear Brake: Tektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-35; 160mm
Front Tyre: Kenda Booster K1227; 26×2.2″; foldable
Rear Tyre: Kenda Booster K1227; 26×2.2″; foldable
Wheel Size: 26″
Rim: Merida CC; 17mm inner rim width; material: aluminium
Spokes: Stainless Black
Front Hub: Shimano TX505; 100x9mm; 32 Spoke; Centerlock
Rear Hub: Shimano TX505; 135x9mm; 32 Spoke; Centerlock
Speeds: 9
Rear Derailleur: Shimano Cues U4000; GS
Shift Levers: Front: Limotec RM06, Rear: Shimano Cues U4050; short reach
Chain: KMC xGlide
Cassette: SunRace U9 CS-U980 9AZ; 11-46 teeth; 9 speed
Chainset: Prowheel A10B; 30 tooth chainset; material: aluminium; Crank length: 140mm
Bottom Bracket: Squared LL123
Pedals: VP VPE-229
Saddle: Merida Expert JR
Seat Post: Merida Comp JR; 30.9mm diameter; 100mm diameter; in-line; material: aluminium
