Description
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 5’3”5’7”
-
- M
- 5’7”5’11”
-
- L
- 5’11”6’3”
-
- XL
- 6’3”6’7”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (inch) | 16.9 | 19.1 | 21.1 | 23 |
| B | Seat Tube Angle | 73.5° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (inch) | 22.2 | 22.8 | 23.4 | 24 |
| D | Head Tube Length (inch) | 4.5 | 5.1 | 6.3 | 7.5 |
| E | Head Tube Angle | 70.0° | 71.0° | 71.0° | 71.0° |
| F | Fork Rake (inch) | 2 | 2 | 2 | 2 |
| G | Trail (inch) | 3 | 2.7 | 2.7 | 2.7 |
| H | Wheelbase (inch) | 42.3 | 42.3 | 43 | 43.6 |
| I | Chain Stay Length (inch) | 17.5 | 17.5 | 17.5 | 17.5 |
| J | Bottom Bracket Drop (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| K | Stack (inch) | 21.2 | 21.9 | 23 | 24.1 |
| L | Reach (inch) | 16 | 16.1 | 16.4 | 16.7 |
| M | Stand Over Height (inch) | 28.1 | 29.7 | 31.5 | 33.1 |
| N | Handlebar Width (inch) | 25.2 | 25.2 | 27.2 | 27.2 |
| O | Stem Length (inch) | 3.5 | 3.5 | 3.9 | 3.9 |
| P | Crank Length (inch) | 6.7 | 6.7 | 6.9 | 6.9 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
Reviews
There are no reviews yet.
